FIGURE

Fig. S3

ID

ZDB-FIG-080904-59

Publication

Kai et al., 2008 - Sphingosine-1-phosphate receptors regulate individual cell behaviours underlying the directed migration of prechordal plate progenitor cells during zebrafish gastrulation

Other Figures

(all 9)

All Figure Page

Back to All Figure Page

Fig. S3

Abrogation of Mil and Edg1 function modulates movements of the presumptive hypothalamus. (A-D) Uninjected WT embryo (A) and WT embryos injected with 4.3 ng mil-MO (B), 6.2 ng edg1-MO (C) or 4.3 ng mil-MO + 6.2 ng edg1-MO (D). The embryos were fixed at tailbud stage for in situ hybridisation with the markers dlx3 (for the anterior edge of the neural plate), pax2.1 (for the prospective mid-hind brain boundary) and nkx2.1 (for the presumptive hypothalamus). The position of the presumptive hypothalamus is highlighted by the dotted lines.

Expression Data

Genes:	dlx3b nkx2.4b pax2a
Fish:	WT WT + MO1-s1pr1 WT + MO1-s1pr2 WT + MO1-s1pr1 + MO1-s1pr2
Knockdown Reagents:	MO1-s1pr1 MO1-s1pr2
Anatomical Terms:	anterior neural plate midbrain hindbrain boundary neural keel neural keel
Stage:	Bud

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-s1pr1 WT + MO1-s1pr2 WT + MO1-s1pr1 + MO1-s1pr2
Knockdown Reagents:	MO1-s1pr1 MO1-s1pr2
Observed In:	cell migration involved in gastrulation neural keel
Stage:	Bud

Phenotype Detail
