Fig. S2

her9 expression in the pronephros and effect of Jagged2/Notch3 knockdown. (A) Expression of her9 in wild-type embryos. her9 is expressed in the neural tube, somites and bilaterally in the pronephros (arrowheads) at 34 hpf. (B) DAPT treatment (100 μM) starting at 9.5 hpf results in a reduction in her9 expression. (C) her9 expression in mind bomb homozygotes is reduced in general and absent from the pronephros. (D) jagged2 exon 20 morpholino injection, (E) notch3 exon 27 morpholino, or (F) a combination of jagged2 exon 20 and jagged2 atg morpholino injection results in loss of her9 expression in the pronephros (arrowheads in F).

Expression Data

Gene:	her9
Fish:	WT mib1^m132/m132 (AB) WT + MO1-jag2b + MO4-jag2b WT + MO4-jag2b WT + MO4-notch3
Condition:	chemical treatment: DAPT
Knockdown Reagents:	MO1-jag2b MO4-jag2b MO4-notch3
Anatomical Terms:	pronephros somite spinal cord
Stage:	Prim-15
