Fig. 6

Sim1 is required for itnp mRNA expression. Itnp and sim1 mRNA was detected by ISHH in embryos that were injected with Morpholino oligonucleotides (MO). A,C,E: Embryos injected with 0.5 ng of a 4-base mismatch "control" sim1 MO. B,D,F: Embryos injected with 0.5 ng of sim1 MO (e.g., sim1 morphants, MOsim1). A, B, E, and F are lateral views, dorsal is up and anterior to the left. C and D are ventral views, anterior is up. The probes are indicated on each panel. A,C: The location of the itnp expression domain is indicated with a white arrowhead. The location of the optic recess (or) is indicated by a black bar. t, telencephalon; m, midbrain; hy, hypothalamus.

Expression Data
Genes:
Fish:
Knockdown Reagent:
Anatomical Terms:
Stage: Long-pec

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Knockdown Reagent:
Observed In:
Stage: Long-pec

Phenotype Detail
