Figure 7—figure supplement 5.

ID: ZDB-IMAGE-220426-60
Source: Figures for Cornean et al., 2022


Figure Caption

Figure 7—figure supplement 5. Confocal microscopy of evoBE4max validated CVD genes.

The full complement of analyzed CVD associated phenotypes in cytosine base editing of myl7::GFP, myl7::H2A-mCherry reporter embryos at 7 dpf. Note the mirroring effect of the confocal microscope used, placing the ventricle to the right, and the atrium to the left in the control. Quantified C-to-T transversions are shown for each imaged embryo for the target codon. Scale bar = 100 µm. dpf = days post fertilization.
