Fig. 3

ID
ZDB-IMAGE-210414-73
Source
Figures for Takahashi et al., 2020
Figure Caption

Fig. 3 Cell proliferation is increased in kzt embryos. kzt homozygotes (kzt–/–) or sibling embryos (kzt+/) were immunostained for phosphorylated histone H3 (pH3) at 48 hpf or 72 hpf. Epifluorescence images or those merged with bright-field images are shown. Images are lateral views of the heads (a1/a1’, b1/b1’), trunk-tail regions (a2/a2’, b2/b2’), and whole embryos (a3/a3’, b3/b3’), with anterior to the left and dorsal to the top. Higher numbers of proliferative cells (stained red) were found throughout kzt homozygote embryos (arrowheads), including the brain at both 48 hpf and 72 hpf. cl, cloaca; e, optic vesicle; hb, hindbrain, mb, midbrain; sc, spinal cord; te, telencephalon. Scale bars, 200 ​μm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 472, Takahashi, K., Ito, Y., Yoshimura, M., Nikaido, M., Yuikawa, T., Kawamura, A., Tsuda, S., Kage, D., Yamasu, K., A globin-family protein, cytoglobin 1, is involved in the development of neural crest-derived tissues and organs in zebrafish, 1-17, Copyright (2020) with permission from Elsevier. Full text @ Dev. Biol.
