Figure Caption

2

Endochondral ossification and intramembranous ossification. (A) 12-day-old G. aculeatus pharyngeal skeleton stained with Alcian Blue for cartilage and Alizarin Red for bone shows intramembranous and endochondral ossification. Italic bold font labels intramembranous ossification and roman font indicates endochondral ossification. The arrow indicates the endochondral ossification centre of the ceratohyal cartilage. (B) Endochondral ossification of ceratohyal of 11 day old spotted gar. Green, Col II staining includes the perichondrium, which surrounds the cartilage core; red, Col X staining in chondrocytes of the ceratohyal; blue, nuclear stain. Abbreviations: bb, basibranchial; bh, basihyal; bsr, branchiostegal ray; cc, chondrocytes; ch, ceratohyal; cl, cleithrum; co, scapulocoracoid; den, dentary; ed, endoskeletal disc; ent, entopterygoid; hs, hyosymplectic; mx, maxilla; me, Meckel's cartilage; op, opercle; pa, pharyngeal arch; pc, perichondrium, pmx, premaxillary; pq, palatoquadrate; ptp, pterygoid process; ra, retroarticular and te, teeth.
