Fig. S1

ID
ZDB-IMAGE-180524-23
Source
Figures for Sánchez-Iranzo et al., 2018
Figure Caption

Fig. S1

Characterization of the tbx5a:GFP reporter line. a Lateral view of a tbx5a:GFP larvae at 3 days postfertilisation. A merged fluorescent and brightfield image is shown. b mRNA in situ hybridization (ISH) with a tbx5a antisense riboprobe on the same staged larvae as the one shown in a (n=7/7). c–g gfp mRNA on embryonic heart sections of tbx5a:GFP fish at different stages of development. The black arrowheads point to the tbx5a:GFP- area of the ventricle. at, atrium; dpf, days postfertilisation; hpf, hours postfertilisation; ht, heart tube; ret, retina; v, ventricle. Scale bars, a, b 100 μm and c, g 25 μm
