Fig. 4

Zebrafish dact3a expression from 60% epiboly through 48 hpf. (A) Specific dact3a expression was not observed at 60% epiboly, even though it is detectable by RT-PCR ( Fig. 3). (D) Dact3a expression in the adaxial mesoderm at the TB stage (black arrow). (B,E) Dact3a expression in the somites (black arrows) and anterior lateral plate mesoderm (white arrowhead) at the 8s stage. (C) Expression at the telencephalon (white arrow), spinal cord neurons (black arrowhead), and the forming somites (black arrow) at the 18s stage. (F) Mandibular (nc1), hyoid (nc2), and branchial (nc3) neural crest expression and medial eye expression (black arrowhead) at the 18s stage. (G-I) Hindbrain expression at 24, 36 and 48 hpf (black arrow). At 36 and 48 hpf, dact3a expression is visible in the pectoral fin bud (red arrow). Inset: Cartilage expression (black arrow) at 48 hpf. A, C, G, H, I are lateral views. B, D, E, F are dorsal views. Anterior up in all the images.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 16(2), Mandal, A., Waxman, J., Retinoic acid negatively regulates dact3b expression in the hindbrain of zebrafish embryos, 122-9, Copyright (2014) with permission from Elsevier. Full text @ Gene Expr. Patterns
