Figure Caption
Fig. S2
Induction of VP-RAR expression using the Tg(hsp70l:EGFP-VP-RAR) line promotes cyp26a1 expression at later stages. (A,B) Wholemount ISH shows cyp26a1 expression is increased after heat-shock at 26 hpf. (C–F) cyp26b1 is modestly increased after heat-shock at 26 hpf in the head, while cyp26c1 is unchanged. (G–J) Rdh10a expression was decreased after heat-shock at 26 hpf, but aldh1a2 expression was overtly unchanged. GFP- denotes non-transgenic siblings, GFP+ denotes embryos with the hsp70l:EGFP-VP-RAR transgene.
