Figure Caption
Fig. 4
Cyp26a1 is required for induction of RA loss of function. (A,C) Gir-/- embryos have expanded hoxb5b expression relative to their siblings. (B,D) Gir-/- embryos injected with vp-rar mRNA have expanded hoxb5b expression, while the remaining gir+/? Embryos lose hoxb5b expression. (E–H) ISH for the sekm cktl and rdh10a in embryos from a gir+/- adult cross show that vp-rar mRNA injected embryos still showed brain defects and rdh10a expression was unchanged.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 405(1), Rydeen, A., Voisin, N., D'Aniello, E., Ravisankar, P., Devignes, C.S., Waxman, J.S., Excessive feedback of Cyp26a1 promotes cell non-autonomous loss of retinoic acid signaling, 47-55, Copyright (2015) with permission from Elsevier. Full text @ Dev. Biol.
