Fig. S3
Effect of ectopic mouse Wnt3a capped mRNA injections on zebrafish embryonic development. (A) Pictures of live embryos in lateral view. Anterior is to the left and posterior to the top. Note the effect of 3 pg mouse Wnt3a mRNA injection on loss of eye field and forebrain. Midbrain-hindbrain barrier (arrows) is still present. Upon injection of 33 pg mouse Wnt3a mRNA or more, the embryos are not able to gastrulate properly. (B) Quantification of the effect of full-length wild-type mouse Wnt3a mRNA on zebrafish embryonic development. Number of embryos analyzed for each condition: non-injected: n = 65, 3 pg: n = 81, 33 pg: n = 82, 100 pg: n = 93 and 150 pg: n = 74. (C) Levels of ectopic mouse Wnt3a protein expression in zebrafish embryos. The Western blot was probed with anti-His5 antibodies. It shows the total levels of His-tagged wild-type mouse Wnt3a and mutant proteins. The same membrane was probed with anti-alpha tubulin as a loading control.
