Figure Caption
Fig. 1 Effect of inhibition of the FGF-receptor on normal development. Live embryos at 48 hpf. (A) Normal embryo, arrows indicate otic vesicle (1), somite 1 (2), and somite 17 (3). (B) Extreme phenotype resulting from expression of the dominant negative FGF-receptor: all structures posterior to the otic vesicle are missing. (C) Homozygous no tail mutant, which lacks only the body axis posterior to somite 17-19, and the notochord.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
