Fig. 3

ID
ZDB-IMAGE-130212-3
Source
Figures for Wang et al., 2013
Figure Caption

Fig. 3 Fusion of Wdr68 to the Mad repression domain is not tolerated in vivo.

A-E) Ventral views of alcian blue stained animals with the Meckel’s (M), palatoquadrate (PQ) and ceratohyal (CH) labeled in red. A) Wildtype sibling. Red arrow indicates the M-PQ jaw joint. B) Severe craniofacial defects in wdr68hi3812 animals and failure of GFP mRNA to rescue. C) Rescue of the severe craniofacial defects by injection of FlagWdr68 (FW) mRNA. Red arrow indicates the mild M-PQ joint fusion phenotype. D) Severe craniofacial defects in wdr68hi3812 animals and failure of MadFlagWdr68 (MFW) mRNA to rescue. 52/52 mutants genotyped were wdr68hi3812 homozygotes. E) Rescue of the severe craniofacial defects by injection of CebpFlagWdr68 (CFW) mRNA. Red arrow indicates the mild M-PQ joint fusion phenotype. F) Graph summarizing the results of four injection trials. In aggregate, n = 112/452 (25%) for GFP animals, n = 16/352 (4.5%) for FW animals, n = 96/296 (32%) for MFW animals, and n = 2/149 (1.3%) for CFW animals.

Figure Data
