Fig. S6
Expression of dharma and vox immediately after HEP induction at the sphere stage. Embryos from crosses of wild-type and HEP+/- transgenic (Tg) fish were exposed to heat shock at the sphere stage, allowed to develop to 45% epiboly at a lower temperature, and then examined for the expression of the genes specified on the left. The numbers of embryos with normal (second column, Sibling-HS) or abnormal (right column, HEP-HS) expression together with the total numbers of embryos examined are shown at the bottom of the respective panels. For the control, marker expression is shown for wild-type embryos (left column). The numbers of embryos with the expression patterns shown in the corresponding panels and total numbers of embryos examined are shown at the bottom of the respective panels. dharma expression was expanded, whereas vox was downregulated, immediately after HEP induction at the sphere stage.
Reprinted from Mechanisms of Development, 129(9-12), Khan, A., Nakamoto, A., Okamoto, S., Tai, M., Nakayama, Y., Kobayashi, K., Kawamura, A., Takeda, H., and Yamasu, K., Pou2, a class V POU-type transcription factor in zebrafish, regulates dorsoventral patterning and convergent extension movement at different blastula stages, 219-235, Copyright (2012) with permission from Elsevier. Full text @ Mech. Dev.
