Fig. S7
Mef2ca and Mef2cb are expressed in hand2 knockdown embryos.
In situ mRNA hybridisation for mef2ca (A) and mef2cb (B) in hearts of control and hand2 MO zebrafish embryos, shown in dorsal view, anterior to top. A and B. Hearts of hand2morphants show cardia bifida phenotype (arrows). CMs on both sides of the midline express both mef2ca and mef2cb. Expression of mef2ca in pharyngeal arches CNC (cranial neural crest) is marked with asterisks. Scale = 100 μm.
