Fig. 2

ID
ZDB-IMAGE-120315-64
Genes
Source
Figures for Shen et al., 2012
Figure Caption

Fig. 2

Expression of mif and mif-like transcripts in the brain, eye and ear during embryogenesis. (A) RT-PCR results of mif-like mRNA from whole embryos at 12, 26, 36, 54, 60, and 72 hpf. (B–U) Whole mount ISH with mif or mif-like probes. (B–E) Dorsal view of 12-hpf embryos; (F–I) Dorsal view of 14-hpf embryos; (J–M) Lateral view of 24-hpf embryos; (N, P) Lateral view of 36-hpf embryos; (O, Q) Lateral view of 48-hpf embryos; (R–U) Lateral view of 72-hpf larvae. (B, F, J, N, O, R) mif antisense probe; (C, G, K, S) mif sense probe; (D, H, L, P, Q, T) mif-like anti-sense probe; (E, I, M, U) mif-like sense probe. Insets in (O) and (Q) show transverse sections through the ear; the small arrow in inset (Q) indicates hair cells in the anterior macula. Arrowheads: brain; OptV: optic vesicle; OV: otic vesicle; white arrows with black outlines: pectoral fin bud. Scale bar: 100 μm for (B–U); 20 μm for insets.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 363(1), Shen, Y.C., Thompson, D.L., Kuah, M.K., Wong, K.L., Wu, K.L., Linn, S.A., Jewett, E.M., Shu-Chien, A.C., and Barald, K.F., The cytokine macrophage migration inhibitory factor (MIF) acts as a neurotrophin in the developing inner ear of the zebrafish, Danio rerio, 84-94, Copyright (2012) with permission from Elsevier. Full text @ Dev. Biol.
