Figure Caption

Fig. S2

Cardiovascular defects caused by morpholino-knockdown of ccm3a/b can be rescued by overexpression of ccm3b mRNA. (A) Light images of ccm3b mRNA injected and non-injected ccm3a/b morphant embryos at 54 hpf. The pronounced pericardial edema and circulatory block observed in 93% of the embryos upon 0.25 ng ccm3a/b morpholino injection (n = 83) are rescued by co-injection of 400 pg ccm3b mRNA. 63% of ccm3a/b morphant embryos injected with ccm3b mRNA had normal heart morphology and completely restored circulation (n = 76). (B) Confocal z-stack projections of dorsal head vasculature in ccm3a/b morphants indicate a decrease in the dilation and misconnections in cranial vessels upon ccm3b mRNA injection (yellow arrows).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 362(2), Yoruk, B., Gillers, B.S., Chi, N.C., and Scott, I.C., Ccm3 functions in a manner distinct from Ccm1 and Ccm2 in a zebrafish model of CCM vascular disease, 121-131, Copyright (2012) with permission from Elsevier. Full text @ Dev. Biol.
