Figures for Balczerski et al., 2012
Figure Caption

Fig. 4

Variable disorganization of Shh-expressing endoderm and fgf8a ectodermal expression in s1pr2 and spns2b1110 mutants. (A–D) In situ hybridizations at 36 hpf show two classes of shha expression in s1pr2 mutants. When viewed dorsally Class 1 mutants have a wider shha endodermal expression domain (green arrows) than Class 2 mutants, and in lateral views of the same embryos Class 1 but not Class 2 mutants display ectopic shha expression (arrowheads) anterior to the normal expression domains (arrows). (E–H) In situ hybridizations at 24 hpf also show two classes of shhb expression in s1pr2 mutants, with Class I mutants (n = 3/8) showing ectopic anterior expression and Class 2 mutants (n = 5/8) displaying posterior truncation of the normal endodermal expression domain (arrows). (I–L) Several examples of spns2b1110 Class I mutants show fragmented expression of fgf8a expression in the oral ectoderm (arrowheads). Scale bar = 50 μm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 361(2), Balczerski, B., Matsutani, M., Castillo, P., Osborne, N., Stainier, D.Y., and Crump, J.G., Analysis of Sphingosine-1-phosphate signaling mutants reveals endodermal requirements for the growth but not dorsoventral patterning of jaw skeletal precursors, 230-241, Copyright (2012) with permission from Elsevier. Full text @ Dev. Biol.
