Fig. 5

ID
ZDB-IMAGE-111020-7
Source
Figures for Sweet et al., 2011
Figure Caption

Fig. 5 Co-misexpression of atoh1a with fgf8 or sox2. (A–L) Expression of brn3c:gfp after serial heat shock at 14 and 16 hpf in a control (A, E), hs:atoh1a (B, F, I, J), hs:atoh1a;hs:fgf8 (C, G, K, L) and hs:atoh1a;hs:sox2 (D, H) embryos. Embryos were fixed and processed at the indicated times. Arrowheads mark positions of endogenous and ectopic sensory epithelia. Images in I–L show transverse sections with dorsal to the top. The boxed areas in I and K are enlarged in J and L, respectively. The hindbrain shows sporadic formation of microvesicles (asterisks), suggesting tissue disruption, and the adjacent wall of the otic vesicle shows marked epithelial thinning (et). All other images show dorsolateral views, with anterior to the left and dorsal to the top.

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 358(1), Sweet, E.M., Vemaraju, S., and Riley, B.B., Sox2 and Fgf interact with Atoh1 to promote sensory competence throughout the zebrafish inner ear, 113-21, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
