Fig. S2

Head vasculature and axonal scaffold in wild type and clo at 24 and 36 hpf. A-L, Maximum intensity confocal projections of immuno-fluorescently stained embryos carrying the endothelial reporter Tg(kdrl:GFP)^1a116. Endothelium, green (GFP). Axonal tracks (acetylated tubulin). Ages (hpf) indicated above. A-H, wild type (wt). I-L, clo (only the red channel is shown for simplicity). Abbreviations (see Table 1): vasculature, white (apostrophe, right side); axonal scafolds, yellow. Small white arrows, CtAs. Yellow asterisk, r5 GFP-positive neuroepithelial signal from the Tg(kdrl:GFP)^1a116 reporter. A, E, I, C, G, K, Dorsal views. Anterior, left. Left side, bottom. B, F, J, D, H, L, Left lateral views. Anterior, left. Dorsal, top. Scale bar (A), 200 μm.
