Fig. 6

ID
ZDB-IMAGE-101104-7
Source
Figures for Raphael et al., 2010
Figure Caption

Fig. 6 Nerves become disorganized during development in mutants lacking Schwann cells. (A-O) Antibody staining for acetylated tubulin shows the position of the PLLn. (A-E) Wild-type nerves remain anchored at the horizontal myoseptum and run straight along the length of the embryo at all times examined (48 hpf, 3-6 dpf), but the neuromasts migrate ventrally over time (arrowheads). Some axons branch from the main bundle to innervate individual neuromasts. (F-O) Nerves in erbb2st61 (F-J) and sox10/clst3 (K-O) mutants appear normal at 48 hpf but become progressively disorganized (3-6 dpf) and often track with migrating neuromasts (arrowheads). Excess neuromasts are present in nerves lacking Schwann cells (F-O). Asterisks indicate the presence of pigment cells. Scale bar: 50 μm.
