Fig. 5

ID
ZDB-IMAGE-100520-23
Source
Figures for Eames et al., 2010
Figure Caption

Fig. 5 Cellular visualization of cartilage and bone morphologies in wild-type and uxs1 mutant larvae. (A–H) Optical sections of live Alizarin red-stained Tg(fli1:EGFP)y1 larvae, ventral views, at 4 dpf and the same individuals at 7 dpf. (E–H) Focus on the ceratohyal. In wild types (A, B, E, F), chondrocytes stacked and were lined with a flattened layer of perichondral cells (white arrow in F). Ossification centers stained with Alizarin red, reflecting perichondral bone formation in the ceratohyal and hyosymplectic and intramembranous ossification in the dentary and maxilla. In homozygous uxs1hi3357 animals (C, D, G, H); however, chondrocytes were disorganized, the perichondral sheath did not align properly (white arrow in H), and Alizarin red-positive ossification centers (dentary, maxilla, and ceratohyal) were severely reduced in perichondral and intramembranous sites. Abbreviations: ch, ceratohyal; de, dentary; hs, hyosymplectic; m, Meckel′s cartilage; max, maxilla; pq, palatoquadrate.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 341(2), Eames, B.F., Singer, A., Smith, G.A., Wood, Z.A., Yan, Y.L., He, X., Polizzi, S.J., Catchen, J.M., Rodriguez-Mari, A., Linbo, T., Raible, D.W., and Postlethwait, J.H., UDP xylose synthase 1 is required for morphogenesis and histogenesis of the craniofacial skeleton, 400-415, Copyright (2010) with permission from Elsevier. Full text @ Dev. Biol.
