Fig. 6

ID
ZDB-IMAGE-100427-17
Genes
Source
Figures for Iwase et al., 2007
Figure Caption

Fig. 6 Brain-Specific Expression and a Role for Smcx in Neuronal Survival during Zebrafish Development

(A) RNA in situ hybridization of whole-mount zebrafish embryos. In (a–f), antisense smcx RNA probe hybridized with embryos at the time points indicated. Arrows point to the neural tube, and arrowheads indicate muscles that were weakly stained. In (g–l), or the control, sense smcx probe hybridized with embryos of the same developmental stages.

(B) Smcx is required for proper neuronal development and survival. Zebrafish embryos injected with two independent antisense morpholinos (MO 1 and 2) to smcx show developmental delay and have abnormal brain patterning (black arrowheads) at 24 hr postfertilization (hpf) compared with embryos injected with a control morpholino. At 48 hpf, knockdown embryos show moderate ventral curvature of the tail. Acridine orange (AO) staining at 30 hpf reveals dramatic cell death throughout the brain (white arrowheads) and neural tube (white arrows) in knockdown embryos.

(C) Transplantation of MO-treated cells to wild-type embryos. Live cell bodies labeled with green dye in the head of most morpholino-treated cells are visible, and often long neuronal processes can be observed (b). Most smcx MO-treated cells with red dye formed small diffuse spots, likely to be dead cell aggregates (c). Bright field view is shown in (a).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Cell, 128(6), Iwase, S., Lan, F., Bayliss, P., de la Torre-Ubieta, L., Huarte, M., Qi, H.H., Whetstine, J.R., Bonni, A., Roberts, T.M., and Shi, Y., The X-linked mental retardation gene SMCX/JARID1C defines a family of histone H3 lysine 4 demethylases, 1077-1088, Copyright (2007) with permission from Elsevier. Full text @ Cell
