Fig. 3

ID
ZDB-IMAGE-091217-50
Genes
Source
Figures for Hammond et al., 2009
Figure Caption

Fig. 3 There are two populations of endochondral osteoblasts with differential sensitivity to Hh signalling. (A) Confocal stacks from wild-type, ptc1-/- and ptc2-/- 6 dpf larvae in an osterix-nuclear GFP background, imaged for GFP expression. The far right image is a single confocal plane to allow distinstintion of the cell morphology. At this stage in both ptc mutants and wild-type larvae, similar numbers of bone collar osteoblasts are present (red arrowheads). However, in ptc1-/- and ptc2-/- larvae, there is a significant increase in the number of chondrocytes that express osterix (blue arrows). A single chondrocyte is outlined in black in the image of the ptc1 mutant. (B) A ventral view of one side of the Meckel′s cartilage and ceratohyal of a 6 dpf wild-type larva stained with Alcian Blue and Alizarin Red; a single chondrocyte is outlined in black to demonstrate the morphology of the chondrocyte cells. (C) Confocal stacks of the ceratohyal from ptc1-/- and wild-type embryos at 3 dpf. In ptc1-/- embryos (but not in wild-type siblings) cells can be found that retain the shape of chondrocytes but that express osterix (blue arrow). (D) Confocal stack of the Meckel′s cartilage of a 9 dpf wild type. Expression of osterix is visible in cells within the cartilage element (blue arrows) and outside (red arrowhead). (E) Confocal stacks of the Meckel′s cartilage of wild-type and ihha-/- 9 dpf larvae. By this stage the wild-type embryo has osterix- expressing bone collar cells (red arrowhead) and transdifferentiating chondrocytes (blue arrows), while the ihha-/- larvae has neither. White arrowheads mark the maxilla, a dermal bone, which forms adjacent to the Meckel′s cartilage. (F) Quantification of number of osteoblasts at 6 dpf showing number of osteoblasts in the bone collar of the Meckle′s cartilage and the number of chondrocytes differentiating as osteoblasts in the Meckel′s cartilage. Data are presented as means±s.d. taken from at least six fish per genotype; asterisk represents P<0.05 in paired Student′s t-tests of mutant versus wild type. (G) Quantification of osteoblast number at 6 dpf in the Meckel′s cartilage of embryos treated with 20 μm purmorphamine or controls. Data are presented as means±s.d. taken from at least four fish per genotype; * represents P<0.05 in paired Student′s t-tests of treated versus untreated. (H) Quantification of osteoblast number at 6 dpf in the Meckel′s cartilage of embryos treated with 75 μM cyclopamine or controls. Data are presented as means±s.d. taken from at least four fish per genotype; * represents P<0.05 in paired Student′s t-tests of treated versus untreated. wt, wild type.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
