Fig. 6

ID
ZDB-IMAGE-090831-31
Genes
Source
Figures for Berberoglu et al., 2009
Figure Caption

Fig. 6 fezf2-GFP expression suggests adult neurogenesis in the caudal hypothalamus. (A) Coronal section through hypothalamus showing double-labeling of fezf2-GFP (green) and BLBP (red) (40x magnification). (A′–A″′) Closer view of the boxed region shows that some fezf2-GFP+ cells colocalize with neural stem cell marker BLBP and have radial glial morphology (arrowhead). (A″′) Inset shows colocalization in cells (depicted by arrowhead) at higher magnification. (B) Double-labeling of fezf2-GFP (green) and neural stem cell marker GFAP (red) (40x magnification). (B′–B″′) Closer view of boxed region shows colocalization in some cells (arrowhead). (B″′) Inset shows colocalization in cells at higher magnification. (C) Double-labeling of fezf2-GFP and proliferating cell marker PCNA (40x magnification). (C′–C″′) Closer view of boxed region shows colocalization in some cells (arrowhead). (C″′) Inset shows colocalization in cells at higher magnification. (D) Double-labeling of fezf2-GFP and neuronal marker Hu (20x magnification). (D′–D″′) Closer view of the boxed region shows colocalization of some fezf2-GFP+ cells with Hu (arrowhead). (D″′) Inset shows colocalization in cells at higher magnification.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 9(6), Berberoglu, M.A., Dong, Z., Mueller, T., and Guo, S., fezf2 expression delineates cells with proliferative potential and expressing markers of neural stem cells in the adult zebrafish brain, 411-422, Copyright (2009) with permission from Elsevier. Full text @ Gene Expr. Patterns
