ZFIN Image: Winata et al., 2009, Fig. S5


Figure Caption

Fig. S5 Rescue of syu^t4 phenotype by purmorphamine (PA). (A–C) Phenotype of control (A,D,G), untreated homozygous syu^t4 (B,E,H), and PA-treated homozygous syu^t4 larvae (C,F,I) at 24 hpf (A–C) and 54 hpf (D–F). (G–I) show EGFP expression in Et(krt4:EGFP)^sq33-2. Note the presence of an anteriorly shifted swimbladder bud in rescued larvae and absence in untreated homozygous mutants. (J–O) Phenotype at 72 hpf, note the presence of a larger swimbladder bud in rescued homozygous syu^t4 compared to the untreated one. Swimbladder bud in rescued larvae is also located one somite more anteriorly compared to that in control. Numbers represent somites. Sb, swimbladder. Scale bars: 250 μm.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 331(2), Winata, C.L., Korzh, S., Kondrychyn, I., Zheng, W., Korzh, V., and Gong, Z., Development of zebrafish swimbladder: the requirement of Hedgehog signaling in specification and organization of the three tissue layers, 222-236, Copyright (2009) with permission from Elsevier. Full text @ Dev. Biol.
