Fig. 2

ID
ZDB-IMAGE-081219-35
Source
Figures for Berndt et al., 2008
Figure Caption

Fig. 2 Imaging of cytokinesis in premigratory NCCs. (A–M) Time-lapse sequences in wild-type embryos showing cytokinesis. (A–E) Dorsal views of rhombomere 2 dorsal neuroepithelium. Parent cell is labeled with green asterisk before division and daughters are labeled with blue and yellow asterisks. A parent cell blebs extensively before division (arrowhead in A). Arrowhead in C indicates a filopodium extended from daughter cell. (F–M) Lateral views of cytokinesis in a mesenchymal NCC adjacent to rhombomere 3. Parent cell is labeled with orange asterisk and daughters with red and yellow asterisks. Arrowhead in G indicates blebbing during cell rounding. Arrowhead in I indicates filopodial protrusion prior to the completion of cytokinesis. Arrowhead in J indicates blebbing after cytokinesis. Arrowhead in L indicates a narrow intercellular bridge connecting daughter cells. Time is in minutes. Scale bars = 20 μm.

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 324(2), Berndt, J.D., Clay, M.R., Langenberg, T., and Halloran, M.C., Rho-kinase and myosin II affect dynamic neural crest cell behaviors during epithelial to mesenchymal transition in vivo, 236-244, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
