Fig. S3

ID
ZDB-IMAGE-080516-24
Genes
Antibodies
Source
Figures for Shin et al., 2008
Figure Caption

Fig. S3 Analysis of apoptosis in med12s435 mutant embryos. (A, A′) Confocal projections of Prox1 (blue) and Actin (red) expression in wild-type and med12s435 mutants in the Tg(gutGFP)s854 line (green) at 34 hpf. White dashed lines surround the endodermal region. (C–F) Confocal projections of wild-type and med12s435 mutants in the Tg(gutGFP)s854 line (green) at 34 (C, D) and 48 (E, F) hpf in conjunction with anti-Prox1 (blue) antibody and TUNEL (red) staining. White dashed lines indicate the midline. In med12s435 mutants, Prox1 expression is mostly missing at 34 hpf but present at 48 hpf. Little if any TUNEL staining was observed in the endodermal tissues at these stages. (G–H) Confocal projections of TUNEL staining in the brain region of wild-type and med12s435 mutants. Asterisks indicate the eyes and arrowheads point to TUNEL-positive cells. Transverse sections, dorsal to the top.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 317(2), Shin, C.H., Chung, W.S., Hong, S.K., Ober, E.A., Verkade, H., Field, H.A., Huisken, J., and Stainier, D.Y., Multiple roles for Med12 in vertebrate endoderm development, 467-479, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
