Fig. 8

ID
ZDB-IMAGE-080506-29
Genes
Source
Figures for Chuang et al., 2001
Figure Caption

Fig. 8 Ectopic expression of eye-determination genes, cell death, and proliferation in rx2-injected embryos. (A-C) Normal expression patterns. (E–G) Ectopic expression of eye-determination genes (arrows). Note in (C) and (G), purple/brown staining shows the endogenous rx2 expression (detected by a probe transcribed from 3′ coding and 3′ UTR sequences that were not present in the injection construct, rx2DC9). In (G), red staining shows the exogenous rx2 (detected by a probe transcribed from rx2ΔC′). (D, H) Dorsal view of living embryos stained with acridine orange. (H) Note more cell death on the left side of the injected embryo. (I-K′) Transverse sections of embryos showing expression of rx1 (I, J, K) and Cy-3 (red fluorescence) staining of mitotic cells and DAPI nuclear staining (I′, J′, K′) of the same sections, respectively. The arrows in (J-K′) indicate ectopic expression of rx1 in forebrain territory in injected embryos. Embryos were injected with 300 pg β-galactosidase (D), 1 ng rx2ΔC′ (E, G), 300 pg rx2ΔRx (H, J-K′), or 600 pg myc-rx2 (F) RNA, and examined at 16 hpf (A-B, E-F), 15 hpf (C, G), or 19 hpf (D, H, I-K′). Rostral is up in (A-H). α-PH3, anti-phosphohistone H3 antibody. Scale bars: 100 μm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 231, Chuang, J.-C. and Raymond, P.A., Zebrafish genes rx1 and rx2 help define the region of forebrain that gives rise to retina, 13-30, Copyright (2001) with permission from Elsevier. Full text @ Dev. Biol.
