Fig. 3

ID
ZDB-IMAGE-080502-8
Genes
Source
Figures for Sanek et al., 2008
Figure Caption

Fig. 3 Zic2a is required for diencephalic neurogenesis. The effect of Zic2a depletion on neurogenesis in the forebrain was examined using ISH with neuronal markers. (A, B) isl1 expression in zic2a morphants at Prim-5 shows loss of the ventrorostral cluster (VRC, arrow), and a fusion of the dorsorostral cluster (DRC, arrowhead) (35/39 embryos, 2 exp.). (C, D) sim1 expression in the preoptic area is strongly reduced (27/36 embryos, 2 exp.) at Prim-5. (E, F) otpb expression in the preoptic area is also strongly reduced (30/30 embryos, 2 exp.). (G, H) Expression of itnp, a marker of differentiated neurons at 2 dpf, is lost in zic2aMO injected embryos (28/34 embryos, 2 exp.). Embryos are shown in lateral view with anterior to the left. Insets are ventral views of the same embryos, except in panels A and B, which are anterio-ventral views. Numbers in panels C and D mark different neural clusters.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 317(1), Sanek, N.A., and Grinblat, Y., A novel role for zebrafish zic2a during forebrain development, 325-335, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
