Fig. S4

ID
ZDB-IMAGE-080324-22
Genes
Source
Figures for Elsen et al., 2008
Figure Caption

Fig. S4 lmx1b.2 and wnt1 expression in overlapping and non-overlapping domains in the hindbrain. (A,A′) lmx1b.2 mRNA and (B,B′) wnt1mRNA in situ hybridization of 24 hpf whole mount hindbrains in dorsal view (A,B) and cross-sections (A′,B′) at the level indicated by the white dotted line in A and B. In the hindbrain, lmx1b.2 is expressed dorsally in the roof plate cells (including the membrane covering the ventricle as well as the “shoulder” region indicated by black arrow in A and A′) and ventrally in the serotonergic neurons (white arrows in A and A′). In the hindbrain, wnt1 expression overlaps with lmx1b.2 expression in the roof plate cells (black arrows in B and B′). wnt1 expression also occurs at elevated levels in the dorsal part of rhombomere boundaries, as well as at lower levels throughout the dorsal hindbrain. The cross-section in B′ indicates the elevated levels of expression of wnt1 at the boundary between r5 and r6. r4, rhombomere 4.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 314(2), Elsen, G.E., Choi, L.Y., Millen, K.J., Grinblat, Y., and Prince, V.E., Zic1 and Zic4 regulate zebrafish roof plate specification and hindbrain ventricle morphogenesis, 376-392, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
