Fig. 2

ID
ZDB-IMAGE-071015-7
Genes
Source
Figures for Stickney et al., 2007
Figure Caption

Fig. 2 Tail patterning is affected in bmp4 mutants. dlx3 (A ,B), flk1 (C, D), myod (E, F), pax2a (G, H), evx1 (I, J) and prdm1 (K, L) expression in 26 hpf wild-type (A, C, E, G, I, K) and bmp4st72 mutant (B, D, F, H, J, L) embryos. Gaps in dlx3 and prdm1 expression in the tail fin (arrow) and reduction of staining in the cloacal region (arrowhead) are apparent in bmp4st72 mutants (B, L). There is also a reduction in the extent of the flk1 expression domain in the tail of bmp4 mutants (D, bracket). Tail somites are fused across the ventral midline (F, arrowhead, inset) and the pronephric terminus is slightly altered in shape and location (H, arrowhead) in bmp4st72 mutants. Expression of evx1 is reduced and more internal in bmp4st72 mutants (J) than in wild-type embryos (I). All views are lateral with anterior to the left except the inset in panel F, which is a dorsal view.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 310(1), Stickney, H.L., Imai, Y., Draper, B., Moens, C. and Talbot, W.S., Zebrafish bmp4 functions during late gastrulation to specify ventroposterior cell fates, 71-84, Copyright (2007) with permission from Elsevier. Full text @ Dev. Biol.
