Figure Caption
Fig. 3 Initial specification of hemato-vascular progenitors is not affected by the lmo2:δBR transgene. Shown are representative sibling embryos that are either control (A) or transgenic for the lmo2:δBR transgene B). Embryos were fixed and processed by in situ hybridization to detect the expression of scl transcripts. In all cases, the initial pattern of scl is normal, as indicated here by the two stripes of lateral mesoderm (arrows) at the two-somite stage.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
