Fig. 2

Expression analysis of zebrafish npr1a. (A) 3 hpf, lateral view, no staining. (B) 14 hpf, lateral view, weak staining. (C) 24 hpf, lateral view, red arrowhead indicates tectal ventricle; green arrowhead indicates pharyngeal arches. (C′) 24hpf, dorsal view, arrowhead indicates tectal ventricle. (D) 36 hpf, lateral view, red arrowhead indicates tectal ventricle; green arrowhead indicates pharyngeal arches. (D′) 36 hpf, dorsal view, arrowhead indicates tectal ventricle. (E) 48 hpf, lateral view, red arrowhead indicates tectal ventricle; green arrowhead indicates pharyngeal arches. (E′) 48 hpf, lateral view, arrowhead indicates tectal ventricle; arrow indicates hindbrain. (F) 72 hpf, lateral view; green arrowhead indicates lens. (F′) 72 hpf, lateral view, yellow arrowhead indicates heart, green arrowhead indicates pharyngeal arche. (F″) 72 hpf, dorsal view, green arrowheads indicate lens; red arrowheads indicate retina (ganglion cell layer). (G) Reverse transcriptase-PCR analysis of zebrafish npr1a.

Expression Data

Gene:	npr1a
Fish:	AB
Anatomical Terms:	brain eye fin heart hindbrain integument kidney lens muscle pharyngeal arch retinal ganglion cell layer tectal ventricle whole organism
Stage Range:	1-cell to Adult

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 29, Gong, J., Chai, L., Xu, G., Ni, Y., Liu, D., The expression of natriuretic peptide receptors in developing zebrafish embryos, 65-71, Copyright (2018) with permission from Elsevier. Full text @ Gene Expr. Patterns
