Fig. 2

Whole mount in situ hybridization of mustn1a at (A-B) 7-somite stage, (C-D) 15-somite stage, (E) 24 h post-fertilization (hfp), (F) 48 hpf, and (G) 72 hpf. (A) Lateral view of must1a expression at 7-somites. (B) Expression of mustn1a in Kupffer′s vesicle (arrowhead). (C) Lateral view of must1a expression at 15 somites with dorsal view in (D). (E) Lateral view of mustn1a expression at 24 hpf. (F) Lateral view of 48 hpf embryo. ov = otic vesicle, f = fin bud. (G) Lateral view of 72 hpf larva with mustn1a expression in the posterior blood island (pbi). Scale bar = 200 µm.

Expression Data

Gene:	mustn1a
Fish:	AB/TU
Anatomical Terms:	anatomical structure head Kupffer's vesicle otic vesicle pectoral fin bud segmental plate somite whole organism (all 8)
Stage Range:	5-9 somites to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene, 593(1), Camarata, T., Vasilyev, A., Hadjiargyrou, M., Cloning of zebrafish Mustn1 orthologs and their expression during early development, 235-41, Copyright (2016) with permission from Elsevier. Full text @ Gene
