ZFIN ID: ZDB-FIG-140701-5
Aigler et al., 2014 - Selection and constraint underlie irreversibility of tooth loss in cypriniform fishes. Proceedings of the National Academy of Sciences of the United States of America   111(21):7707-12 Full text @ Proc. Natl. Acad. Sci. USA
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Anatomical Term:
Stage Range: Pec-fin to Protruding-mouth
PHENOTYPE:
Fish:
Observed In:
Stage: Days 7-13

Fig. 3

Ectopic Eda expression restores upper pharyngeal teeth to the zebrafish. Lower pharyngeal teeth (arrows) in lateral (A) and transverse (B) views of wild-type alizarin red-stained larvae. (C and D) bmp2b expression is limited to tooth germs (arrows) of the lower pharynx in wild-type. Upper pharyngeal teeth (arrowheads) in lateral (E) and transverse (F) views of ef1α:eda transgenic zebrafish. (G) bmp2b expression is induced in the upper pharyngeal epithelium (arrowhead) by ectopic eda expression and becomes limited to tooth germs (arrowhead) at later stages (H). Abbreviations: cb5, fifth ceratobranchial; cl, cleithrum; cp, chewing pad; d, dentary bone; n, notochord; y, yolk. (Scale bars, 50 μm.)

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
bmp2b WT standard conditions Pec-fin tooth placode ISH
Protruding-mouth tooth placode ISH
cs1Tg; cs3Tg standard conditions Pec-fin tooth placode ISH
Protruding-mouth tooth placode ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
cs1Tg; cs3Tg standard conditions Days 7-13 ceratobranchial 5 tooth increased amount, abnormal
Days 7-13 ceratobranchial 5 tooth mislocalised, abnormal
