FIGURE

Fig. 1

ID

ZDB-FIG-110902-1

Publication

Lele et al., 2001 - Zebrafish admp is required to restrict the size of the organizer and to promote posterior and ventral development

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

Expression of admp in wild-type zebrafish embryos analyzed by whole-mount in situ hybridization: (A) 40% epiboly, animal pole view; (B) shield stage, lateral view; (C) shield stage, dorsal view; (D) 70% epiboly, lateral view; (E) 70% epiboly, dorsal view; (F) tailbud stage, dorsal view (the embryo is slightly tilted upward to expose the tailbud region); (G) 8-somite stage, lateral view; (H) 8-somite stage, dorsal view of the tailbud region. Arrows in C,E,F point to expression in the mesoderm; arrowheads in C–E point to expression in the neuroectoderm.

Expression Data

Gene:	admp
Fish:	WT
Anatomical Terms:	anterior presumptive neural plate notochord posterior region presumptive shield shield
Stage Range:	30%-epiboly to 5-9 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
