Fig. 7

her8a expression in the early neural plate is partially dependent on the expression of SoxB factors. Dorsal views of flat-mounted embryos analyzed at the 5-somite stage (A-F) and 3-somite stage (G-H) for the expression of the genes indicated (color-coded). A-F. her8a expression overlaps with that of the Sox family members sox2, sox3, sox19a, sox19b and sox21a, including the mid- and anterior hindbrain (red brackets). G-I. the simultaneous knockdown of sox2/3/19a/19b and 21a causes a reduction of her8a expression in the MH area of the early neural plate (white arrows).

Expression Data

Genes:	her8a sox2 sox3 sox19a sox19b sox21a (all 6)
Fish:	WT WT + MO3-sox19a + MO3-sox19b + MO3-sox21a + MO5-sox2,sox3
Knockdown Reagents:	MO3-sox19a MO3-sox19b MO3-sox21a MO5-sox2,sox3
Anatomical Terms:	hindbrain neural keel anterior region midbrain hindbrain boundary neural plate midbrain neural keel midbrain neural rod presumptive diencephalon ventral region presumptive rhombomere 3 presumptive telencephalon (all 7)
Stage Range:	1-4 somites to 5-9 somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO3-sox19a + MO3-sox19b + MO3-sox21a + MO5-sox2,sox3
Knockdown Reagents:	MO3-sox19a MO3-sox19b MO3-sox21a MO5-sox2,sox3
Observed In:	hindbrain neural keel midbrain hindbrain boundary neural keel midbrain neural keel
Stage:	1-4 somites

Phenotype Detail
