FIGURE

Fig. S2

ID

ZDB-FIG-090804-90

Publication

Nikolaou et al., 2009 - Lunatic fringe promotes the lateral inhibition of neurogenesis

Other Figures

All Figure Page

Back to All Figure Page

Fig. S2

Knockdown of lfng does not affect hindbrain boundary formation or segmentation. Dorsal views of control MO (A-D) and lfng^E1I1 MO (E-H) injected embryos at 16 hpf (C,D,G,H) and 24 hpf (A,B,E,F), showing rfng (A,E), foxb1.2 (B,F), krox20 (C,G) and ephrin B3 (D,H) mRNA expression in the hindbrain. The arrows in A, B, E and F indicate boundary expression. Scale bars: 100 μm in A for A,B,E,F; 100 μm in C for C,D,G,H.

Expression Data

Genes:	efnb3b egr2a foxb1a rfng
Fish:	WT WT + MO2-lfng
Knockdown Reagent:	MO2-lfng
Anatomical Term:	hindbrain
Stage Range:	14-19 somites to Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
