Fig. 3

Gene expression domains of myoglobin during zebrafish development in sections of long pec and 5dpf embryos. Shown are sections of whole mount in situ hybridized embryos at the indicated stages. Abbreviations used are: basihyal (bh), ceratohyal (ch), diencephalon (di), epidermis (ep), ganglion cell layer (gcl), inner nuclear layer (inl), intermandibularis posterior (imp), intestine (int), liver (lv), meckel’s cartilage (mc), midbrain (mb), notochord (nt), optic chiasm (oc), otic vesicle (ov), palatoquadrate (pq), pancreas (p), sensory epithelium (se), somites (som) and telencephalon (tel).

Expression Data

Gene:	mb
Fish:	WT
Anatomical Terms:	basihyal cartilage ceratohyal cartilage diencephalon epidermis lens liver Meckel's cartilage midbrain notochord optic chiasm otic vesicle palatoquadrate cartilage pancreas pectoral fin bud retina retinal ganglion cell layer retinal inner nuclear layer sensory epithelial cell telencephalon (all 19)
Stage Range:	Long-pec to Day 5
