Fig. 3
zfIsl-3 mRNA expression in the body of a 19-hr embryo. (A) A photomontaged lateral view. Anterior, left; dorsal, up. (B) A cryostat cross section made at the rostrocaudal level indicated by the arrow in A. S, spinal cord; N, notochord. zfIsl-3 mRNA was expressed intensely in the ventral myotomes [brackets] and the Rohon-Beard neurons (RB) and weakly in the ventromedial regions (arrowheads) of the dorsal myotomes. Bar, 100 μm (A) and 25 μm (B). |
Expression Data
Expression Detail
Antibody Labeling
Phenotype Data
Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 171, Tokumoto, M., Gong, Z.Y., Tsubokawa, T., Hew, C.L., Uyemura, K., Hotta, Y., and Okamoto, H., Molecular heterogeneity among primary motoneurons and within myotomes revealed by the differential mRNA expression of novel islet-1 homologs in embryonic zebrafish, 578-589, Copyright (1995) with permission from Elsevier. Full text @ Dev. Biol.
