Fig. 3

Spatial expression pattern of ZF-RNases-1. Whole-mount in situ hybridization experiments were carried out on early and late embryo stages. A, views of embryos showing the expression of ZF-RNases-1 at shield stage. The arrow indicates the anterior part of embryo and the arrowhead the posterior part. B, expression of ZF-RNases-1 at 3-somite stage; the arrow indicates the presumptive head. C, expression of ZF-RNases-1 at 24 hpf; D is a magnification (20x) of the boxed area in C. E, expression of ZF-RNases-1 at 48 hpf stage; the arrow indicates the heart. Abbreviations used: T, telencephalon; D, diencephalon; M, mesencephalon; H, hearth. Scale bar = 250 μm.

Expression Data

Gene:	rnasel1
Fish:	WT
Anatomical Terms:	axis diencephalon head heart midbrain telencephalon trunk (all 7)
Stage Range:	Shield to Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene, 427(1-2), Quarto, N., Pizzo, E., and D'Alessio, G., Temporal and spatial expression of RNases from zebrafish (Danio rerio), 32-41, Copyright (2008) with permission from Elsevier. Full text @ Gene
