Fig. 2

MLF growth cones fasciculate along neighboring MLF axons and are inhibited by surrounding tissue.(a, b) Images from time-lapse sequence of MLF axon outgrowth in uninjected Tg(pitx2c:gfp) embryos. Ventral views, anterior to the left, midline is up. Asterisks denote the caudal-most nucMLF cell. (a) The arrows indicate the position of the growth cone that fasciculates along a neighboring MLF axon. (b) The arrowheads label the growth cone that is repelled by surrounding tissue. The time stamp shows hours: minutes. Scale bar = 25 μm.

Expression Data

Gene:	EGFP
Fish:	zy8Tg
Anatomical Term:	nucleus of the medial longitudinal fasciculus synencephalon
Stage:	14-19 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
