FIGURE

Fig. 8

ID
ZDB-FIG-060215-8
Publication
Schier et al., 1997 - The one-eyed pinhead gene functions in mesoderm and endoderm formation in zebrafish and interacts with no tail
Other Figures
All Figure Page
Back to All Figure Page
Fig. 8

Phenotype of oep flh and oep ntl double mutants. Comparison of wild-type (A), and floating head (flh; B), no tail (ntl; C), one-eyed pinhead (oep; D), one-eyed pinhead; floating head double (oep flh; E), and one-eyed pinhead; no tail double (oep ntl; F) mutant embryos at 28 hpf. Arrow indicates the notochord, arrowhead indicates posterior region. Note the mainly additive features of oep flh double mutants as compared to the severe defects in oep ntl double mutants.

Expression Data

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Observed In:
Stage: Prim-5

Phenotype Detail
