Fig. 5

Nodal signaling is required for maintenance, but not initiation, of dpr2 expression. Embryos were probed for zebrafish dpr2. A-L: MZoep mutant embryos. M-X: Wild-type control embryos. Developmental stages are indicated. G-L: Arrowheads in G and H and arrows in I,J,K,L indicate ectodermal dpr2 expression in MZoep mutant embryos. X: Arrows indicate ectodermal expression. A,C,E,G,I,K,M,O,Q,S,U,W are lateral views. B,D,F,H,N,P,R,T are animal views. Dorsal is to the right, except in J,L,V,X, which are dorsal views. In J,L,V,X, anterior is upward. Note that, because later epiboly (epib.) movements are delayed in MZoep embryos, dpr2 expression in MZoep embryos at 70% and 90% epiboly is compared with wild-type embryos at 90% epiboly and tail bud stages, respectively.

Expression Data
Gene:
Fish:
Anatomical Terms:
Stage Range: Sphere to Bud

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
