ZFIN Image: Parichy et al., 2009, Fig. 10


Figure Caption

Fig. 10 Changes in swim bladder morphology. Shown is a single individual, viewed from ventrolaterally (standard length [SL] at lower right of each panel). Larvae initially have a single, posterior swim bladder lobe. A second, anterior lobe appears as a bud adjacent to the posterior lobe, then inflates within a short period of time. Images shown are at decreasing magnifications. Scale bars = 6.1 and 7.9, 250 μm.

Developmental Stage

Days 30-44 to Adult

Figure Data

Anatomy Term: swim bladder
