Fig. 4.

ID
ZDB-IMAGE-211025-112
Genes
Source
Figures for Robinson et al., 2021
Figure Caption

Fig. 4. Transgenic zebrafish expressing human ataxin-3 with 84 glutamines develop ataxin-3+ protein aggregates. (A) Confocal microscopy was performed on 6-day-old zebrafish larvae expressing EGFP-tagged human ataxin-3 containing a short polyglutamine stretch (28Q) or long polyglutamine stretch (84Q). (B) Manual counting of EGFP aggregates revealed that significantly more aggregates were present in 6-dpf zebrafish expressing EGFP ataxin-3 84Q than those expressing EGFP ataxin-3 23Q. (C) Quantification of the percentage of cells harbouring protein aggregates revealed that a greater number of cells were affected with aggregates in zebrafish expressing EGFP ataxin-3 84Q. (D) Measurement of the size of protein aggregates observed via confocal microscopy revealed that zebrafish expressing EGFP ataxin-3 84Q also display aggregates that are significantly larger in size compared to the aggregates found in zebrafish expressing EGFP ataxin-3 23Q. (E) Western blotting was used to examine the relative expression of human ataxin-3 across the examined genotypes. (F) Densiometric analysis revealed significantly greater expression of EGFP-fused human ataxin-3 in transgenic zebrafish compared to non-transgenic siblings. Data are meanĀ±s.e.m. *P<0.05; **P<0.01; ***P<0.001; ****P<0.0001; ns, not significant (one-way ANOVA with Tukey's post-hoc test or Student's t-test, paired, two-tailed). n=4-5 experimental replicates.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dis. Model. Mech.
