FIGURE 1

ID: ZDB-IMAGE-210520-9
Source: Figures for Liu et al., 2021


Figure Caption

FIGURE 1

The mutant^cas008 line showed defective definitive hematopoiesis. WISH analysis of myb(A,A′), ae1-globin(B,B′), lyz(C,C′), mpx(D,D′), and rag1(E,E′) expression in sibling (A–E) and mutant^cas008(A′–E′) embryos at 5 dpf. The penetrance of the indicated phenotype is shown in the bottom right of each panel. Black arrows indicate the position of CHT, while red arrows and circles show the position of thymus and kidney, respectively.
