Figure 4

ID: ZDB-IMAGE-210508-6
Source: Figures for DeLaurier et al., 2021


Figure Caption

Figure 4 Skeletal structure is normal in <italic>kdm1a</italic> maternal zygotic mutants.

Wild-type larvae (A–C) compared with kdm1a maternal zygotic mutant larvae (D–F). (A and D) Whole mount specimens, lateral view of head skeleton, (B and E) flat mount pharyngeal skeleton, pharyngeal arches 1 and 2, lateral view, (C and F) flat mount neurocranium, ventral view. Fish larvae are stained as described in Fig. 3. Scale bar = 200 microns.
