Figure Caption
Fig. 4 zic2a and zic5 expression pattern at 24hpf and 48hpf. In situ hybridization of zic2a (A, A′, C, C′) and zic5(B, B′, D, D′) in the wide type embryos at 24hpf (A-B′, arrows indicate expression signal) and 48hpf (C-D′, arrows indicate expression signal). Dorsal is upwards; anterior is leftwards. Scale bar = 150 μm in A′, B′, C′, D'.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Gene expression patterns : GEP, 39, Zhang, Q., Li, T., Zhang, Y., Lin, J., Chen, X., Gui, Y., Li, Q., Comparative sequence analysis and functional validation identified a retina-specific enhancer around zic5 and zic2a, 119162, Copyright (2020) with permission from Elsevier. Full text @ Gene Expr. Patterns
